This single-eye spring entry records a 26-1/8-inch eye-to-slipper distance, 2-inch width and five leaves. The source capacity field is 3,500 lbs.
Listed details
| Capacity | 3,500 lbs |
|---|---|
| Eye to Slipper Distance | 26-1/8″ |
| Eye Diameter | 9/16″ |
| Bushing | Included: Nylon |
| Number of Leaves | 5 |
| Spring Width | 2″ |
These details are transcribed from the supplied listing and await manufacturer verification.
Before selecting this part
Compare the slipper end shape and hanger contact arrangement as well as eye diameter. This end style must be matched to the suspension; it is not a direct substitute for a double-eye spring.
