This double-eye spring source lists 2,600 lbs capacity, a 25-1/4-inch eye spacing and a 1.44-inch stack height. Its dimensions and rating differ from the lighter spring even though both have four leaves.
Listed details
| Capacity | 2,600 lbs |
|---|---|
| Eye to Eye Distance | 25-1/4″ |
| Eye Diameter | 9/16″ |
| Bushing | Included: Nylon |
| Number of Leaves | 4 |
| Stack Height | 1.44″ |
| Spring Width | 1.75″ |
These details are transcribed from the supplied listing and await manufacturer verification.
Before selecting this part
Compare spring width, stack height and the manufacturer's unloaded measurement method. Confirm the rating definition and suspension geometry before substituting this spring.
