Ensure reliable braking performance and safety with this 12″ Electric Brake Assembly. This complete assembly is designed for easy installation and reliable operation, providing peace of mind on every journey.
- COMPLETE ASSEMBLY: Comes fully assembled with all necessary components, including brake shoes, magnet, and springs, for a quick and hassle-free replacement.
- RIGHT-HAND ORIENTATION: Specifically designed for the right-hand side of your trailer, ensuring correct fit and function for your electric braking system.
- DURABLE CONSTRUCTION: Built with high-quality materials to withstand the demands of regular use and provide long-lasting performance.
- ENHANCED SAFETY: Provides reliable stopping power for your trailer, contributing to overall road safety and control.
Specifications
| Used For | Brake Backing Plate Complete with Shoes, Springs, and Magnet |
|---|---|
| Fits Trailer Type | Universal |
| Fits Trailer Brand | Universal |
| Fits Axle Size | 5,200 – 6,000 lb |
| Adjuster Type | Manual |
| Application Type | Electric |
| Driver / Passenger | Passenger Side |
| Shoe Width | 2″ |
| Compatible Hub | Hub and Drum 6 on 5-1/2 Complete with Bearings 05-AX5200-HD Hub and Drum 8 on 6-1/2 Complete with Bearings 05-AX7000-DRUM |
| Axle Mounting Flange | 5 Bolt, 3/8″-24 006-193-00 |
| Torque Spec | 45-50 ft lbs |
| Adjustment Interval | First 200 miles, Every 3,000 miles |
| Recommended Wire Size | 2-4 Brakes: 12 AWG, 6 Brakes: 10 AWG |
| Cross Reference | 023-106-00 |
